Advanced Ground Power Units for Fixed-Wing Aircraft

Proven Performance: With a steadfast history of excellence, StartStick has provided reliable power solutions for a wide range of fixed-wing aircraft, earning trust from esteemed operators such as those flying the Vision Jet, AW109, AW139, PC-24, Citation Series, and more. With over 2500 units deployed worldwide, StartStick continues to revolutionize ground power for fixed-wing aviation. Explore our application guide for compatibility with even more aircraft models.

When you purchase a StartStick, you receive:

• StartStick
• International 28-volt Power Supply
• Includes 120/220V 50/60hzs battery charger
• Additional components as per the selected kit
• 2-year warranty

Start Stick 10

• Capacity: 9.7 Ah
• Max Current (Pulse): 800 Amps
• Max Current (Cont.): 200 Amps
• Weight: 4.81 kg (10.60 lbs)
• Length: 432 mm (17.25 in)
• Width: 157 mm (7.31 in)
• Time to Discharge:* 29 min
• Charge Time (approx): 2.8 hrs

Start Stick 15

• Capacity: 14.7 Ah
• Max Current (Pulse): 1600 Amps
• Max Current (Cont.): 300 Amps
• Weight: 6.76 kg (14.9 lbs)
• Length: 539 mm (21.21 in)
• Width: 157 mm (6.19 in)
• Time to Discharge:* 44 min
• Charge Time (approx): 4.2 hrs

Start Stick 20

• Capacity: 19.4 Ah
• Max Current (Pulse): 1600 Amps
• Max Current (Cont.): 400 Amps
• Weight: 9.21 kg (20.20 lbs)
• Length: 438 mm (21.21 in)
• Width: 185 mm (6.19 in)
• Time to Discharge:* 60 min
• Charge Time (approx): 5.6 hrs

All Models

No. of Starts:
** 3-4 starts/charge

Charge Cycles:
*** >1000 cycles

AC Charger Input:
110/240 volts (50/60 hz)

In-flight Charge Rating:
5 amps

Operating Temperature:
0-60°C

Storage Temperature:
-40-60°C (-40-140°F)

* Assuming 20 Amp Load
** Using StartStick application chart
*** Capacity Checks <80% of rated, ambient temp

High Power Design: The StartStick’s cableless design, combined with highly conductive interconnects and a patent-pending power electronics design, enables it to deliver over 30% more power than other lithium batteries. This innovative approach allows the StartStick’s compact form factor to achieve a higher power output than significantly larger and heavier lithium batteries.

Integrated Auto-Charger: StartStick’s smart battery management system includes redundant temperature sensing and an integrated smart charger that continuously monitors over twenty-five different parameters to determine if it is safe to charge. This also allows the StartStick to charge on-board, automatically sensing when a generator/alternator is running before charging starts.

Auto-Shut Off: The StartStick actively monitors itself and will shut down if it exceeds a specified level of time without being used or charged, ensuring peace of mind.

Smart is Safe: At the heart of the StartStick is an electronic battery management system unlike any other. Running over 12K lines of code, its fully integrated charger, battery monitor, data logger, display, and high-speed controller sense and control all aspects of the battery chemistry and external environment to keep the battery safe in all conditions, contributing to our perfect safety record.

Designed to Last: With internal components, a hardened case, and software designed to deliver 10 years of service or 3k-5k engine starts, StartStick ensures longevity. Its software notifies users if they exceed any design limit, optimizing performance over its lifetime. If an issue arises, all components are fully serviceable and can be overhauled by the factory or one of our certified repair centers.

State of Health = State of Mind: StartStick’s comprehensive design and intelligent monitoring provide users with confidence in their equipment’s reliability and performance, ensuring peace of mind in critical situations.

Multiposition Extension Adapter: The StartStick Multiposition Extension Adapter is engineered to seamlessly integrate with aircraft featuring recessed GPU receptacles like the PC12, PC24, and AS350 fitted with Squirrel Cheeks. it eliminates fitment concerns as this adapter ensures secure connectivity without any hassle.

StartStick 180 Adapter: This accessory, originally designed for Bell aircraft, ensures the display is visible from the top/front for added convenience.

StartStick Single Operator Kit: Designed to secure the StartStick to the side of the aircraft while charging, this kit relieves weight from the GPU connector during operation, allowing operators to start the aircraft and complete other tasks efficiently and confidently.

Replacement Charger: Do you need another charger for your StartStick?Our Replacement Charger is designed with precision and built for compatibility, ensuring seamless power whenever you need it.

StartStick Extension Cable, 3 Foot: Designed for single pilot operators who prefer the StartStick to rest on a platform or in a stowage compartment during operation. Commonly used in business jets such as the CJ3, PC12, PC24, AW139, and A119. Other lengths up to 5ft are available by request.

Pelican Hard Case: Designed to provide unparalleled protection for your device, this case is engineered with custom-molded foam to cradle your equipment securely, guaranteeing a safe journey during transport and storage. Partnering with the renowned toughness of Pelican, this case ensures top-notch protection in any condition, offering peace of mind wherever your operations take you. Available for StartStick 10 and 20.
